CuBe2Pb - Cuivre au Béryllium et Plomb

Shapes Available

CuBe2Pb - Cuivre au Béryllium et Plomb

Cuivre au béryllium et au plomb

Request a Quote

Cu (1) Al Be Co (2) Pb Si
Min/Max Rem. .20 1.8 - 2.00 .20 min .20 - .6 .20
Nominals 97.7 - 1.90 - .40 -
Temper Sect. Size Cold Work Type Min Temp Tensile Strength YS
0.05% UL
YS
0.02% Offset
YS
0.005% Offset
Elong. RH
B
RH
C
RH
F
RH
30T
VH
500
BH
500
BH
3000
Shear
Strgth
Fatigue
Strgth
Izod
Impact
Strgth
- in. % - F ksi ksi ksi ksi % B C F 30T 500 500 3000 ksi ksi ft-lb
- mm. - - C MPa MPa MPa MPa - - - - - - - - MPa MPa J
Rod
TH04 1.1 0 TYP 68 190 - 175 - 3 - - - - - - - - 41 0.0
- 0.0 - - 20 1310 - 1207 - 3 - - - - - - - - 283 0.0
TF00 0.0 0 TYP 68 182 - 130 - 6 - 39 - - - - - - - 0.0
- 0.0 - - 20 1255 - 896 - 6 - 39 - - - - - - - 0.0
TD04 1 0 TYP 68 105 - 90 - 15 95 - - - - - - - - 0.0
- 25.4 - 20 724 - 621 - 15 95 - - - - - - - - - 0.0
TH04 0.375 0 TYP 68 200 - 90 - 3 - - - - - - - - - 0.0
- 0.0 - - 20 1379 - 621 - 3 - - - - - - - - - 0.0
TD04 1.1 0 TYP 68 100 - 90 - 15 95 - - - - - - - - 0.0
- 25.4 - 20 689 - 621 - 15 95 - - - - - - - - - 0.0
TD04 0.375 0 TYP 68 112 - 90 - 15 95 - - - - - - - - 0.0
- 9.525 - - 20 772 - 621 - 15 95 - - - - - - - - 0.0
TB00 0.0 0 TYP 68 68 - 25 - 48 6 - - 62 - - - - - 0.0
- 0.0 - - 20 469 - 172 - 48 6 - - 62 - - - - - 0.0
TH04 1 0 TYP 68 195 - 178 - 5 - - - - - - - - - 0.0
- 0.0 - - 20 1344 - 1227 - 5 - - - - - - - - - 0.0
WIRE
TF00 0.0 0 TYP 68 178 - 160 - 3 - - - - - - - - - 0.0
- 0.0 - - 20 1227 - 1103 - 3 - - - - - - - - - 0.0
TD04 0.0 0 TYP 68 152 - 125 - 1 - - - - - - - - - 0.0
- 0.0 - - 20 1048 - 162 - 1 - - - - - - - - - 0.0
TD02 0.0 0 TYP 68 122 - 100 - 5 - - - - -- - - - - 0.0
- 0.0 - - 20 841 - 689 - 5 - - - - - - - - - 0.0
TH03 0.0 0 TYP 68 210 - 190 - 1 - - - - - - - - - 0.0
- 0.0 - - 20 1448 - 1310 - 1 - - - - - - - - - 0.0
TH04 0.0 0 TYP 68 212 - 195 - 1 - - - - -- - - - - 0.0
- 2 - - 20 1462 - 1344 - 1 - - - - - - - - - 0.0
TH02 0.0 0 TYP 68 200 - 185 - 1 - - - - - - - - - 0.0
- 0.0 - - 20 1379 - 1276 - 1 - - - - - - - - - 0.0
TB00 0.00 0 TYP 68 68 - 28 - 35 - - - - - - - - - 0.0
- 0.0 - - 20 469 - 193 - 35 - - - - - - - - - 0.0
TD03 0.0 0 TYP 68 142 - 120 - 2 - - - - - - - - - 0.0
- 0.0 - - 20 979 - 827 - 2 - - - - - - - - - 0.0
TH01 0.0 0 TYP 68 190 - 175 - 2 - - - - -- - - - - 0.0
- 0.0 - - 20 1310 - 1207 - 2 - - - - - - - - - 0.0
TD01 0.0 0 TYP 68 102 - 82 - 10 - - - - - - - - - 0.0
- 0.0 - - 20 703 - 565 - 10 - - - - - - - - - 0.0
- US Customary Metric
Melting Point - Liquidus 1800 F 982 C
Melting Point - Solidus 1590 F 866 C
Density 0.298 lb/in3 at 68 F 8.25 gm/cm3 @ 20 C
Specific Gravity 8.260 8.26
Electrical Resistivity 46.20 ohms-cmil/ft @ 68 F 7.68 microhm-cm @ 20 C
Electrical Conductivity 22 %IACS @ 68 F 0.129 MegaSiemens/cm @ 20 C
Thermal Conductivity 62 Btu . ft/(hr . ft2 . oF)at 68F 107.3 W/m . oK at 20 C
Modulas of Elasticity in Tension 18500 ksi 128000 MPa
Modulus of Rigidity 7300 ksi 50330 MPa
Specific Heat Capacity 0.090 Btu/lb/°F at 68 F 377.1 J/kg . °K at 293 K
Joining Technique Suitability
Brazing Good
Butt Weld Fair
Capacity for Being Cold Worked Excellent
Capacity for Being Hot Formed Good
Coated Metal Arc Welding Good
Gas Sheilded Arc Welding Good
Machinability rating 50
Oxyacetylene Welding Not Recommended
Seam Weld Fair
Soldering Good
Spot Weld Good
Product Type Temper Type
Bar

ASTM B196

Military Mil-C-21657

Rod

ASTM B196

Military Mil-C-21657

Wire ASTM B197
